Aluminium pcb board 2835 led smd PCBA LED BULB PCB

Product Description

Aluminium PCB board 2835 led smd PCBA LED BULB PCB Aabout PCBQuick PCBQuick is a PCB supplier that offers quick online quote service. We can provide customized solutions for LED lighting PCB and UPS PCB. Our Rigid pcb/ FPC/LED PCB/PCBA is exported to all parts of the world. PCBQuick continuously improves the quality and service. By the end of 2018, we have already served more than 300 companies worldwide.   Why us ? 1) Professional engineer team --help you to check design and do engineering before production 2) Rich expierences in pcb production industry--provide high quality and competitive price pcb. 3) After-sales service--every problem you have will get our professional advice and solution. 4) Constant follow up-- make us have the fast reaction of your requirement. 5) Inspected by the Inspection Institution--ISO,UL,ROHS cerfiticated Our Service We are able to provide you best electronics services. 1) PCB Production Service. (FR-4,HI-TG,Aluminum,FPC,TEFLON,Rogers,CEM-1 ) 2) FPC,PCB Copy Service. 3) PCB Assembly Service. (SMT, BGA, DIP) 4) PCBA Final Functional Testing. 5) PCBA Copy Service. 6) Electronic Components Purchasing & BOM List Purchasing Services. 7) PCB SMT Stencil. (Laser cut & Etching) Process Capability
Aluminum PCB Process capability
NO Item Craft Ability
1

Product Type

Al Clad PCB 1 layer

2

Maximum Panel size

1470mm*600mm

3

Copper thickness

0.5oz, 1oz, 2oz, 3oz

4

Dielectric Thickness(to Substrate)

0.05mm, 0.075mm, 0.1mm, 0.15mm, 0.2mm

5

Substrate Core Thickness

0.4mm,0.6mm,0.8mm,1.0mm,1.2mm,1.5mm,2.0mm,3.0mm,3.2mm

6

Finished Board Thickness

0.4mm To 4.0mm

7

Thickness Tolerance

+/- 10%

8

Aluminum Machining

Drilling,Tapping,Milling, Routing, Die-Punching,break-off tab available

9

Min. Finish hole size

0.25mm

10

Max. working voltage

2.5k VDC(0.075mm Dielectric) 3.75k VDC(0.15mm Dielectric)

11

Min. Track Width

0.2mm (8mils)

12

Min. Track gap

0.2mm (8mils)

13

Min. SMD pad pitch

0.2mm (8mils)

14

Surface Finishing

HASL, HASLLeadfree, Immersion gold, OSP

15

Solder mask color

White, LED light special White, Black, MATT Black, others Available

16

Legend color

Black, White, others Available

17

E-test

YES

18

Rosh

YES

19

Reference Standard

IPC-A-600G Class 2

20

Special holes

Spot facing, Cup holes

21

Data Input

Gerbers, AutoCad, Cam350,

PROTEL99SE,PROTEL,DXP,POWER PCB.


  Welcome to ask us ! Production Flow PCB&PCBA Products Certifications FAQ Q1.What is needed for quotation? PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...) PCBA: PCB information, BOM,( 57832695,Testing documents...)   Q2. What file formats do you accept for production? Gerber file: CAM350 RS274X PCB file: Protel 99SE, P-CAD 2001 PCB BOM: Excel (PDF,word,txt)   Q3. Are my files safe? Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.   Q4. MOQ? There is no MOQ in POE.We are able to handle Small as well as large volume production with flexibility.   Q5.Shipping cost? The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.

Contact us if you need more details on led smd pcb board. We are ready to answer your questions on packaging, logistics, certification or any other aspects about aluminium led pcb、pcb supplier. If these products fail to match your need, please contact us and we would like to provide relevant information.
